Clemco Wetblast Injector

Sku: P-BMCWBFINJ

• Efficient Wet-Blasting Conversion
  • Converts any 2 CF or larger dry-blast machine into a wet-blasting system.
  • Mixes water and abrasive at the nozzle for enhanced operator control.
  • Significantly reduces job site dust, improving visibility and reducing cleanup.
  • Minimizes the need for expensive containment solutions.
  • Allows for easy surface rinsing and drying by controlling water flow.
• Simple Operation & Setup
  • Easy installation at the nozzle—no need for extensive modifications.
  • Abrasive flow adjusted at the machine’s metering valve.
  • Water injection controlled at the nozzle, allowing for immediate adjustments.
  • When using an optional abrasive cut-off system, operators can easily switch between blasting, rinsing, and drying.
• Versatile Kit Options
  • Single-Operator Kit Includes:
    • Pump assembly
    • 50-ft water hose
    • Nozzle adaptor assembly
  • Dual-Operator Kit Includes:
    • Pump assembly
    • Two 50-ft water hoses
    • Two nozzle adaptor assemblies
• Precision Water Control
  • Needle-valve controlled water consumption
    • 0.25 GPM at 60 PSI during blasting (adjustable based on conditions).
    • Up to 2.8 GPM for washdown applications.
    • Allows for fine-tuning water flow to balance dust suppression and blasting efficiency.

• Information Pump Type: Air-operated, positive-displacement, self-priming pump Pump Ratio: 10:1
• Air Consumption: 28 CFM at 100 PSI
• Water Consumption:
  • 0.25 GPM at 60 PSI during blasting
  • Up to 2.8 GPM for washdown
• Water Flow Control: Needle-valve adjustable
• Fittings:
  • ½” air inlet
  • ¾” water inlet
  • ½” tee to two ¼” main water outlet connections
  • ¼” individual water outlet
• Water Hose:
  • 3/8” ID x 50 ft
  • Rated 1000 PSI

• Construction and Infrastructure Projects – Ideal for dust-sensitive urban environments.
• Industrial Surface Preparation – Reduces dust when removing coatings, rust, and contaminants.
• Marine and Shipbuilding – Enhances visibility and safety when blasting in enclosed spaces.
• Tank and Pipeline Maintenance – Supports easy rinsing and drying after blasting.
• Confined Space Blasting – Reduces airborne contaminants for a safer work environment.
